Ford Truck Bodies at Kelly Ford




Looking for the right truck body upfit for your Ford truck? Shop our selection of dump bodies, service bodies and rack bodies at Kelly Ford! Browse our truck body inventory below and then use the form on this page to submit your truck body request.



Jump to Dump Bodies Section



DuraClass 2/3 Yard 9' Dump Body (F-350)

Standard Equipment:

- 2 Vertical Side Braces per Side
- 20" Ends and 14" Sides
- 3/4 Size 8 Ga. Cabshield
- Set of Tall Front Pockets
- Electric 1520 Hoist w/Power Up and Power Down
- Continuous Formed Body Sidewall and Fully Enclosed Top Rail
- Double-Wall Body Side
- Full Depth Rear Corner Posts and Enclosed Front Corner Posts
- Interlaced Sub Frame to Give Uncommon Strength and Rigidity to Body
- 1/2" Tow Plate w/Pintle Hitch, D-Rings and Trailer Plug
- Pioneer Manual Load Cover
- Quick Release Pin Tailgate
- Under Body Undercoating
- Body-up Alarm and Light/Backup Alarm

Optional Features: Pocket Extension for Side Boards, Additional Coal Chute


Description:

Backed by over 100 years, the DuraClass Yardbird is the premium light duty choice for contractors and municipalities who don't want to compromise quality and durability. The Yardbird features our patented DuraClass design, with a continuous formed body sidewall and fully enclosed top rail for superior resistance to moisture and corrosion.

The double-wall body side, a standard Yardbird feature, withstands punishing loads and always looks good. The full depth rear corner posts and enclosed front corner posts, plus our famous interlaced understructure gives Yardbird uncommon strength and rigidity for a light duty dump body. Yardbirds come standard with quick release upper tailgate pins, 1/4 cabshield with window and heavy duty tailgate hardware. Choose from additional options including a crossmemberless understructure, drop sides, and stainless steel construction.



-----------------------------------------------------------------------------------------------------------------






DuraClass 2/3 Yard 9' Dropside Dump Body (F-350)

Standard Equipment:

- 2 Vertical Side Braces per Side
- 20" Ends and 14" Sides
- 3/4 Size 8 Ga. Cabshield
- Set of Tall Front Pockets
- Electric 1520 Hoist w/Power Up and Power Down
- Continuous Formed Body Sidewall and Fully Enclosed Top Rail
- Double-Wall Body Side
- Full Depth Rear Corner Posts and Enclosed Front Corner Posts
- Interlaced Sub Frame to Give Uncommon Strength and Rigidity to Body
- 1/2" Tow Plate w/Pintle Hitch, D-Rings and Trailer Plug
- Pioneer Manual Load Cover
- Quick Release Pin Tailgate
- Under Body Undercoating
- Body-up Alarm and Light/Backup Alarm

Optional Features: Pocket Extension for Side Boards, Additional Coal Chute


Description:

Backed by over 100 years, the DuraClass Yardbird is the premium light duty choice for contractors and municipalities who don't want to compromise quality and durability. The Yardbird features our patented DuraClass design, with a continuous formed body sidewall and fully enclosed top rail for superior resistance to moisture and corrosion.

The double-wall body side, a standard Yardbird feature, withstands punishing loads and always looks good. The full depth rear corner posts and enclosed front corner posts, plus our famous interlaced understructure gives Yardbird uncommon strength and rigidity for a light duty dump body. Yardbirds come standard with quick release upper tailgate pins, 1/4 cabshield with window and heavy duty tailgate hardware. Choose from additional options including a crossmemberless understructure, drop sides, and stainless steel construction.



-----------------------------------------------------------------------------------------------------------------






DuraClass 3/4 Yard 9' Dump Body (F-450/F-550)

Standard Equipment:

- 2 Vertical Side Braces per Side
- 24" Ends and 18" Sides
- 3/4 Size 8 Ga. Cabshield
- Set of Tall Front Pockets
- Electric 1520 Hoist w/Power Up and Power Down
- Continuous Formed Body Sidewall and Fully Enclosed Top Rail
- Double-Wall Body Side
- Full Depth Rear Corner Posts and Enclosed Front Corner Posts
- Interlaced Sub Frame to Give Uncommon Strength and Rigidity to Body
- 1/2" Tow Plate w/Pintle Hitch, D-Rings and Trailer Plug
- Pioneer Manual Load Cover
- Quick Release Pin Tailgate
- Under Body Undercoating
- Body-up Alarm and Light/Backup Alarm

Optional Features: Pocket Extension for Side Boards, Additional Coal Chute


Description:

The DuraClass Yardbird is the dump body of choice for contractors and municipalities who don't want to compromise on quality and durability. The Yardbird features our patented DuraClass design, with a continuous formed body sidewall and fully enclosed top rail for superior resistance to moisture and corrosion. Yardbird, like all DuraClass dump bodies, uses high tensile steel and fully welded construction for outstanding strength while saving precious weight.

The double-wall body side, a standard Yardbird feature, withstands punishing loads and always looks good. The full depth rear corner posts and enclosed front corner posts, plus our famous interlaced understructure give Yardbird uncommon strength and rigidity for a light duty dump body. Yardbirds come standard with quick release upper tailgate pins, 1/4 cabshield with window and heavy duty tailgate hardware. Choose from additional options including a crossmemberless under-structure, drop sides, and stainless steel construction.



-----------------------------------------------------------------------------------------------------------------






DuraClass 3/4 Yard 9' Dropside Dump Body
(F-450/F-550)

Standard Equipment:

- 2 Vertical Side Braces per Side
- 24" Ends and 18" Sides
- 3/4 Size 8 Ga. Cabshield
- Set of Tall Front Pockets
- Electric 1520 Hoist w/Power Up and Power Down
- Continuous Formed Body Sidewall and Fully Enclosed Top Rail
- Double-Wall Body Side
- Full Depth Rear Corner Posts and Enclosed Front Corner Posts
- Interlaced Sub Frame to Give Uncommon Strength and Rigidity to Body
- 1/2" Tow Plate w/Pintle Hitch, D-Rings and Trailer Plug
- Pioneer Manual Load Cover
- Quick Release Pin Tailgate
- Under Body Undercoating
- Body-up Alarm and Light/Backup Alarm

Optional Features: Pocket Extension for Side Boards, Additional Coal Chute


Description:

The DuraClass Yardbird is the dump body of choice for contractors and municipalities who don't want to compromise on quality and durability. The Yardbird features our patented DuraClass design, with a continuous formed body sidewall and fully enclosed top rail for superior resistance to moisture and corrosion. Yardbird, like all DuraClass dump bodies, uses high tensile steel and fully welded construction for outstanding strength while saving precious weight.

The double-wall body side, a standard Yardbird feature, withstands punishing loads and always looks good. The full depth rear corner posts and enclosed front corner posts, plus our famous interlaced understructure give Yardbird uncommon strength and rigidity for a light duty dump body. Yardbirds come standard with quick release upper tailgate pins, 1/4 cabshield with window and heavy duty tailgate hardware. Choose from additional options including a crossmemberless under-structure, drop sides, and stainless steel construction.



-----------------------------------------------------------------------------------------------------------------






DuraClass SL 5/6 Yard 10' Dump Body (F-750)

Standard Equipment:

- Semi-Automatic Load Cover
- 17 Ton Hoist
- Wishbone Type Hoist
- Combo Hitch and Plate
- 7 Pin Trailer Wiring
- Paint to Match Cab
- Heavy-duty Tailgate
- Double-wall Construction on Body
- 3/4 Cab Protector
- Under-body Undercoating
- Body-up Alarm and Light

Optional Features: Pocket Extension for Side Boards, Additional Coal Chute


Description:

For your toughest loads, meet your needs with DuraClass SL. A stacked under-structure of 4" I-beam crossmembers and 6" I-beam long-members give you the maximum floor support. Six-panel tailgate and vertical side braces are standard on this rough and ready body.


Specifications:

Body Length: 10'
Body Inch: 4"
Body OD: 96"
Hoist Model: 1821
Hydraulics: Direct Mount-Clockwise Single Acting Hydraulics
Understructure: 8 Ga. High Tensile Steel, 4" Crossmembers Interlaced Through 9" Longmembers
Understructure Spacing: 20" Standard
Yardage: 5.1/6.4
Front Height: 30"
Side Height: 24"
Tailgate Height: 30"
Side Bracing: Min Two 4 1/2 Vertical Side Braces Front Flared To 9" at the Body. 6" Board Pockets
Rear Pillar Width: 10.25
Tailgate Release: Manual
Tailgate Bracing Style: Three panel design. 2 Verticals
Light Carton: LED Light Kit w/Harness
Cab Shield: 3/4 Size 8 Ga.
Plate: 1/2" Tow Plate w/Pintle Hitch, D-Rings and Trailer Plug


-----------------------------------------------------------------------------------------------------------------






Duramag 2/3 Yard 9' HD Dump Body

Standard Equipment:

- All Extruded 6005 T6 Alum Construction
- 2x6 .250 Long Sills
- Extruded Unibody Floor w/2" OC Bracing
- Extruded Interlocking Walls w/Honeycomb Construction
- Extruded Interlocking Tailgate w/SS Hinge Pins
- SS Tailgate Actuator Hardware and Fasteners
- All Pre-Wired w/LED Lights Inside Box Tube
- Aluminum Cab Shield w/Window
- Hoist - Champion Scissor-Type Push Control Double Acting Hoist (Installed)


Dimensions:

- 96" x 111", 14" Sides and 21" Tailgate

-----------------------------------------------------------------------------------------------------------------






Duramag 3/4 Yard 9' HD Dump Body

Standard Equipment:

- All Extruded 6005 T6 Alum Construction
- 2x6 .250 Long Sills
- Extruded Unibody Floor w/2" OC Bracing
- Extruded Interlocking Walls w/Honeycomb Construction
- Extruded Interlocking Tailgate w/SS Hinge Pins
- SS Tailgate Actuator Hardware and Fasteners
- All Pre-Wired w/LED Lights Inside Box Tube
- Aluminum Cab Shield w/Window
- Hoist - Champion Scissor-Type Push Control Double Acting Hoist (Installed)


Dimensions:

- 96" x 111", 20" Sides and 27" Tailgate

-----------------------------------------------------------------------------------------------------------------


Ford Truck Rack Bodies






8'6" Palfinger Rack Body
Note: Requires 60" Cab to Axle

Standard Equipment:

- Steel Rack Construction
- ICC Bumper
- Black Coating
- Steel Heavy-Duty Side Gussets Construction
- Back-up Alarm

Optional Features: Plate and Combo Hitch and Pin Wiring D-Rings, Hoist 13-Ton Power Up/Down, Body Up Alarm - 9' and 12' Bodies, Swing-out Racks for Omaha, Rub Rails (9'), Rub Rails (12'),
Rub Rails (14'), Rub Rails (16')

Description:
Palfinger Standard products have set the industry standard for more than 80 years and we offer the widest selection of truck equipment available from one manufacturer. Our nationwide network of dedicated professional truck equipment distributors insures prompt delivery, quality installation, and outstanding service. Our electrocoat paint (e-coat) gives you the ultimate in coverage and rust resistance. And, if you want a Ford commercial truck tailor-made to meet your Massachusetts driving needs, we can also make custom bodies to your exact specifications.


-----------------------------------------------------------------------------------------------------------------






9'6" Palfinger Rack Body
Note: Requires 60" Cab to Axle

Standard Equipment:

- Steel Rack Construction
- ICC Bumper
- Black Coating
- Steel Heavy-Duty Side Gussets Construction
- Back-up Alarm

Optional Features: Plate and Combo Hitch and Pin Wiring D-Rings, Hoist 13-Ton Power Up/Down, Body Up Alarm - 9' and 12' Bodies, Swing-out Racks for Omaha, Rub Rails (9'), Rub Rails (12'),
Rub Rails (14'), Rub Rails (16')

Description:
Palfinger Standard products have set the industry standard for more than 80 years and we offer the widest selection of truck equipment available from one manufacturer. Our nationwide network of dedicated professional truck equipment distributors insures prompt delivery, quality installation, and outstanding service. Our electrocoat paint (e-coat) gives you the ultimate in coverage and rust resistance. And, if you want a Ford commercial truck tailor-made to meet your Massachusetts driving needs, we can also make custom bodies to your exact specifications.


-----------------------------------------------------------------------------------------------------------------






12' Palfinger HD Rack Body
Note: Requires 84" Cab to Axle

Standard Equipment:

- Steel Rack Construction
- ICC Bumper
- Black Coating
- Steel Heavy-Duty Side Gussets Construction
- Back-up Alarm

Optional Features: Plate and Combo Hitch and Pin Wiring D-Rings, Hoist 13-Ton Power Up/Down, Body Up Alarm - 9' and 12' Bodies, Swing-out Racks for Omaha, Rub Rails (9'), Rub Rails (12'),
Rub Rails (14'), Rub Rails (16')

Description:
Palfinger Standard products have set the industry standard for more than 80 years and we offer the widest selection of truck equipment available from one manufacturer. Our nationwide network of dedicated professional truck equipment distributors insures prompt delivery, quality installation, and outstanding service. Our electrocoat paint (e-coat) gives you the ultimate in coverage and rust resistance. And, if you want a Ford commercial truck tailor-made to meet your Massachusetts driving needs, we can also make custom bodies to your exact specifications.


-----------------------------------------------------------------------------------------------------------------






9'4" Rugby Platform Body

Standard Equipment:

- High Tensile Steel Rub Rails Are Heavy Duty 12 Ga. High Strength Low Alloy Steel
- Full Depth Rear Apron
- LED Lighting
- Fully Enclosed Stake Pocket with Outside of Wall Being Double Lined For Extra Support
- 10 Ga. Cross Sills Are Welded To Structural Steel Long Sills and Reinforced with 6" x 12" Gussets
- Clearance Lights Mount In Heavy Rubber Grommets and Conform to D.O.T. Regulation
- Structural Steel Channel Long Sills
- Wood Floors Are of 2x6 #1 Dense Pressure Treated Tongue and Groove Yellow Pine with Wolmonized Extra

-----------------------------------------------------------------------------------------------------------------






12'4" Rugby Rack Body

Standard Equipment:

- 42" Steel Racks
- Full Rear Apron
- Double-Walled Stake Pockets


Optional Features: Plate and Combo Hitch and Pin Wiring D-Rings, Hoist 13-Ton Power Up/Down, Body Up Alarm - 9' and 12' Bodies, Rub Rails (9'), Rub Rails (12'),
Rub Rails (14'), Rub Rails (16')


Description:
Rugby's Series 2000 Platform Bodies are built to exceed your highest expectations at a price that makes your decision easy. Available in 3 styles: standard duty with internal stake pockets, heavy duty with external stake pockets and tie down rails, and super heavy duty with a frame made almost entirely of structural channel.


-----------------------------------------------------------------------------------------------------------------






14'4" Rugby Rack Body

Standard Equipment:

- High Tensile Steel Rub Rails
- Full Rear Apron
- Double-Walled Stake Pockets


Optional Features: Plate and Combo Hitch and Pin Wiring D-Rings, Hoist 13-Ton Power Up/Down, Body Up Alarm - 9' and 12' Bodies, Swing-out Racks for Omaha, Rub Rails (9'), Rub Rails (12'),
Rub Rails (14'), Rub Rails (16')

Description:
Rugby's Series 2000 Platform Bodies are built to exceed your highest expectations at a price that makes your decision easy. Available in 3 styles: standard duty with internal stake pockets, heavy duty with external stake pockets and tie down rails, and super heavy duty with a frame made almost entirely of structural channel.


-----------------------------------------------------------------------------------------------------------------






9' Duramag Aluminum Rack Body

Standard Equipment:

- All Extruded 6005 T6 Alum Box Tube Construction
- 2x3 .188 Long Sills
- 2x3 .125 Cross Members, 24" OC
- G-Tube Perimeter Frame
- T&G Extruded Alum Flooring
- Square Headboard w/Exp Metal Window
- All Pre-Wired w/LED Lights Inside Box Tube
- Stake Pockets & Rub Rail
- 40" Anti-Rattle Rack Body System

Dimensions:

- 97" x 116 1/2", Long Sills @34"


-----------------------------------------------------------------------------------------------------------------





12' Duramag Aluminum Rack Body

Standard Equipment:

- All Extruded 6005 T6 Alum Box Tube Construction
- 2x3 .188 Long Sills
- 2x3 .125 Cross Members, 24" OC
- G-Tube Perimeter Frame
- T&G Extruded Alum Flooring
- Square Headboard w/Exp Metal Window
- All Pre-Wired w/LED Lights Inside Box Tube
- Stake Pockets & Rub Rail
- 40" Anti-Rattle Rack Body System

Dimensions:

- 97" x 146 1/2", Long Sills @34"

-----------------------------------------------------------------------------------------------------------------


Ford Truck Service Bodies




Palfinger 6.5' Utility SW w/Bumper Service Body


Standard Equipment:

- SB80-40 Service Body
- 12 Ga. x 48.5" W Floor
- Standard Height 40" H x 15" D Compartment
- "V" Configuration Both Sides
- Light Holes In Rear End Panels
- 2 Divider Trays Front SS
- 1 Divider Tray Horizontal SS
- 1 Shelf Rear SS
- 2 Divider Trays Front CS
- 1 Shelf Rear CS
- Grip Strut Bumper w/Recess

Optional Features: Power Locks, Compartment Lights, Trailer Hitch 12,000 lb. Capacity, Receiver w/Ball (Accessory Item For Bolt On Hitch), Combo Hitch w/Receiver (Accessory Item For Bolt On Hitch)


Description:

- Full-length rust resistant stainless steel door hinges. Internal bolt on attachment gives optimum security and ease of replacement vs. competitor's riveted/welded on door hinges. Heavier 1/4" diameter stainless steel hinge pin vs. competitor's 1/8" diameter pin 100% larger

- Bonding compartment door panels together with structural automotive epoxy adhesive results in the strongest, most rigid doors of any service body on the market. No welds mean less chance of rusting

- Adjustable bolted on large diameter striker pins combined with automotive rotary door latches provide positive door closure

- Exclusive vertical "legs" of intermediate cross members rest on truck frame to provide maximum body support in critical wheel well area

- Strongest under-structure of any service body 7 Ga. full-width formed channel cross members vs. competitor's 11 Ga. cross members 50% thicker material. Front cross member reinforced with 7 Ga. plates at body mounting points. Cross members are bolted to side compartments to give maximum support. Entire body underside has automotive type undercoating

- Standard stainless steel paddle latches

- Blind bolt stud mounting vs. competitors' riveted on metal latches results in greater security and ease of replacement. Optional stylized automotive rotary paddle latches match truck door handles and are available for a slight up-charge

- Full perimeter weatherproof automotive bulb type neoprene door seals. Double spring door retainers on full-sized vertical doors to hold doors in positive open or closed position

- Entire body exterior made from 14 Ga. A-60 two sided galvanized zinc coated steel

- Interior light guards provide light protection and routing for wire harness. Light guards are bracket mounted and easily removable for light maintenance. Competitors' light guards are welded to body making it difficult to install/service the lights

- Palfinger service bodies receive complete electrocoat primer paint coverage. Because they are e-coated before the doors are installed (unlike the competitors' bodies) Omaha service bodies get total paint coverage, including behind the door hinges. This means superior rust protection in critical areas



-----------------------------------------------------------------------------------------------------------------






Palfinger 8' Utility SRW Service Body
Note: 56" Cab To Axle

Standard Equipment:

- Omaha Palfinger 96V 8' Service Body
- 12 Ga. x 48.5" W Floor
- Standard Height 40" H x 15" D Compartment
- "V" Configuration Both Sides
- 2 Divider Trays Front SS
- 1 Divider Tray Horizontal SS
- 1 Shelf Rear SS
- 2 Divider Trays Front CS
- 1 Shelf Rear CS
- E-coat Epoxy Primer
- Standard Version Light Kit

Optional Features: Power Locks, Compartment Lights, Trailer Hitch 12,000 lb. Capacity, Receiver w/Ball (Accessory Item For Bolt On Hitch), Combo Hitch w/Receiver (Accessory Item For Bolt On Hitch)


Description:

- Full-length rust resistant stainless steel door hinges. Internal bolt on attachment gives optimum security and ease of replacement vs. competitor's riveted/welded on door hinges. Heavier 1/4" diameter stainless steel hinge pin vs. competitor's 1/8" diameter pin 100% larger

- Bonding compartment door panels together with structural automotive epoxy adhesive results in the strongest, most rigid doors of any service body on the market. No welds mean less chance of rusting

- Adjustable bolted on large diameter striker pins combined with automotive rotary door latches provide positive door closure

- Exclusive vertical "legs" of intermediate cross members rest on truck frame to provide maximum body support in critical wheel well area

- Strongest under-structure of any service body 7 Ga. full-width formed channel cross members vs. competitor's 11 Ga. cross members 50% thicker material. Front cross member reinforced with 7 Ga. plates at body mounting points. Cross members are bolted to side compartments to give maximum support. Entire body underside has automotive type undercoating

- Standard stainless steel paddle latches

- Blind bolt stud mounting vs. competitors' riveted on metal latches results in greater security and ease of replacement. Optional stylized automotive rotary paddle latches match truck door handles and are available for a slight up-charge

- Full perimeter weatherproof automotive bulb type neoprene door seals. Double spring door retainers on full-sized vertical doors to hold doors in positive open or closed position

- Entire body exterior made from 14 Ga. A-60 two sided galvanized zinc coated steel

- Interior light guards provide light protection and routing for wire harness. Light guards are bracket mounted and easily removable for light maintenance. Competitors' light guards are welded to body making it difficult to install/service the lights

- Palfinger service bodies receive complete electrocoat primer paint coverage. Because they are e-coated before the doors are installed (unlike the competitors' bodies) Omaha service bodies get total paint coverage, including behind the door hinges. This means superior rust protection in critical areas



-----------------------------------------------------------------------------------------------------------------






Palfinger 11' Utility DRW Service Body
Note: 60" Cab To Axle

Standard Equipment:

- 1/8 x 54.5 W Floor
- Standard Height 40" H x 20" D Compartment
- "V" Configuration Both Sides
- Light Holes in End Panels
- 2 Divider Trays Front SS
- 2 Divider Tray 2nd Front Comp SS
- 1 Divider Tray Horizontal SS
- 1 Shelf Rear SS
- 2 Divider Trays Front CS
- 2 Divider Trays 2nd Rear Comp SS
- 1 Shelf Rear CS
- Standard Light Kit

Optional Features: Power Locks, Compartment Lights, Trailer Hitch 12,000 lb. Capacity, Receiver w/Ball (Accessory Item For Bolt On Hitch), Combo Hitch w/Receiver (Accessory Item For Bolt On Hitch)


Description:

- Full-length rust resistant stainless steel door hinges. Internal bolt on attachment gives optimum security and ease of replacement vs. competitor's riveted/welded on door hinges. Heavier 1/4" diameter stainless steel hinge pin vs. competitor's 1/8" diameter pin 100% larger

- Bonding compartment door panels together with structural automotive epoxy adhesive results in the strongest, most rigid doors of any service body on the market. No welds mean less chance of rusting

- Adjustable bolted on large diameter striker pins combined with automotive rotary door latches provide positive door closure

- Exclusive vertical "legs" of intermediate cross members rest on truck frame to provide maximum body support in critical wheel well area

- Strongest under-structure of any service body 7 Ga. full-width formed channel cross members vs. competitor's 11 Ga. cross members 50% thicker material. Front cross member reinforced with 7 Ga. plates at body mounting points. Cross members are bolted to side compartments to give maximum support. Entire body underside has automotive type undercoating

- Standard stainless steel paddle latches

- Blind bolt stud mounting vs. competitors' riveted on metal latches results in greater security and ease of replacement. Optional stylized automotive rotary paddle latches match truck door handles and are available for a slight up-charge

- Full perimeter weatherproof automotive bulb type neoprene door seals. Double spring door retainers on full-sized vertical doors to hold doors in positive open or closed position

- Entire body exterior made from 14 Ga. A-60 two sided galvanized zinc coated steel

- Interior light guards provide light protection and routing for wire harness. Light guards are bracket mounted and easily removable for light maintenance. Competitors' light guards are welded to body making it difficult to install/service the lights

- Palfinger service bodies receive complete electrocoat primer paint coverage. Because they are e-coated before the doors are installed (unlike the competitors' bodies) Omaha service bodies get total paint coverage, including behind the door hinges. This means superior rust protection in critical areas



-----------------------------------------------------------------------------------------------------------------






Stahl Challenger 8' Utility ST Series SRW
Service Body



Standard Equipment:

- Stahl ChallengerST Service Body
- Lighted Bumper
- Standard Compartment Configuration
- 2 Adjustable Trays with Dividers in SS and CS Front Vertical
- 1 Adjustable Tray with Dividers on CS Horizontal
- 1 Adjustable Tray with Dividers on SS and CS Rear Vertical

Optional Features: Compartment Lights, Trailer Hitch 12,000 lb. Capacity, Receiver w/Ball (Accessory Item For Bolt On Hitch), Combo Hitch w/Receiver (Accessory Item For Bolt On Hitch)


Description:

The STAHL Challenger ST II Service Body (CST) is a rugged, highly versatile tool box on wheels. Its sleek exterior design includes full-height, lockable compartment doors; fully concealed door hinges and hidden drip-rails - standard features that enhance your company's image while protecting your tools and equipment from theft and the elements.

Constructed of heavy gauge, powder coated Galvanneal steel, CST II bodies feature a minimum 44 cu. ft. of secure, sealed storage space. With a wide array of optional equipment including drawers, racks, compressors, generators, welders and more, you can easily configure the ChallengerST II to meet your specific application needs.


-----------------------------------------------------------------------------------------------------------------






Stahl 9' Utility Dual Rear Wheel w/Bumper Service Body


Standard Equipment:

- Stahl ChallengerST Service Body
- Lighted Bumper
- Standard Compartment Configuration
- 2 Adjustable Trays with Dividers in SS and CS Front Vertical
- 1 Adjustable Tray with Dividers on CS Horizontal
- 1 Adjustable Tray with Dividers on SS and CS Rear Vertical

Optional Features: Compartment Lights, Trailer Hitch 12,000 lb. Capacity, Receiver w/Ball (Accessory Item For Bolt On Hitch), Combo Hitch w/Receiver (Accessory Item For Bolt On Hitch)


Description:

The STAHL Challenger ST II Service Body (CST) is a rugged, highly versatile tool box on wheels. Its sleek exterior design includes full-height, lockable compartment doors; fully concealed door hinges and hidden drip-rails - standard features that enhance your company's image while protecting your tools and equipment from theft and the elements.

Constructed of heavy gauge, powder coated Galvanneal steel, CST II bodies feature a minimum 44 cu. ft. of secure, sealed storage space. With a wide array of optional equipment including drawers, racks, compressors, generators, welders and more, you can easily configure the ChallengerST II to meet your specific application needs.


-----------------------------------------------------------------------------------------------------------------







8' Reading U98ASW Classic II Service Body


Standard Equipment:

- Patented Hidden Hinges
- Slam Action Tailgate
- Pooched, From-Mounted Bumper
- Nitrogen Strut Door Holders
- LED Lights
- Heavy-duty Compartment Doors
- Exclusive Dual-Pro Door Seal System
- Stainless Steel Rotary Locks
- Galvanized Shelves
- A60 Coating Weight Pressed Diamond Plate Floor and Tailgate Facer Plate
- Aluminum-Fuel Fill
- Powder Coat White/Black/Red
- Heavy-duty Compartment Doors

Optional Features: TruckCraft Remote Electric Locks, Receiver Tube Trailer Hitch with 7 Prong Flat Plug, 2-Stage Paint Upgrade


-----------------------------------------------------------------------------------------------------------------






Truckcraft TC-250 8' Lancer Service Body
(F-250/F-350 SRW 56" CA Chassis)



Standard Equipment:

- 6061 T-6 Aluminum Floor, .090 Aluminum Sheet Cabinets
- 21.4 Cu. Ft. Secure Storage
- 8' Length
- 40" H x 13.5" D x 98" L Aluminum Side Compartments
- A-A Door Configuration
- 1/8" Thick Diamond Plate Compartment Tops
- T-handle, Black Polymer Twist Lock Latches
- Single Handle Drop Tailgate
- Powder Coated White, Black, or Red
- 8' Straight Bumper with LED S/T/T Lights
- Backup Alarm
- Mud Flaps
- Heavy-duty Compartment Doors

Optional Features: TruckCraft Remote Electric Locks, Receiver Tube Trailer Hitch with 7 Prong Flat Plug, 2-Stage Paint Upgrade





Ford Truck Body Upfit Equipment Request Form





Contact

Kelly Ford

420 Cabot St (Rte 1A)
Directions Beverly, MA 01915

  • Sales: (866) 809-7483
  • Service: (978) 922-0059
  • Parts: (978) 922-0059
; ;
